Marzouk Steel, based in Tunis, Tunisia, has built a solid reputation as a reliable manufacturer and supplier of top-notch ARCELOR 500 sheets and plates. Known for its state-of-the-art steel production facilities and rigorous quality control, the company adheres to international standards, providing high-performance steel solutions tailored for demanding industrial needs. The ARCELOR 500 sheets and plates are designed to offer outstanding wear resistance, toughness, and structural integrity, making them perfect for heavy-duty applications. Catering to the mining, construction, and material handling sectors, Marzouk Steel delivers robust and dependable steel products that promise longevity, operational efficiency, and cost-effective performance in challenging environments.
The ARCELOR 500 sheets and plates from Marzouk Steel are crafted from high-carbon alloy steel, with carefully controlled amounts of chromium, manganese, and other alloying elements. This specific blend achieves a nominal hardness of around 500 BHN, ensuring exceptional abrasion resistance and toughness. The mechanical properties boast high tensile and yield strength, impressive impact resistance, and durability even in extreme conditions. Through advanced quenching and heat treatment processes, the hardness is optimized while still preserving ductility. Each plate is subjected to thorough chemical and mechanical testing to guarantee consistent quality and reliable performance in high-wear and high-stress industrial settings.
Item: ARCELOR 500
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness MM | %C Max | %Mn Max | %P Max | %S Max | %SI Max | %Cr Max | %Ni Max | %Mo Max | B Max | CE Max | PCM Max |
| 6.0 – 20.0 | 0.60 | 0.41 | |||||||||
| 21.0 – 40.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.50 | 1.50 | 0.70 | 0.040 | 0.65 | 0.43 |
| 41.0 – 50.0 | 0.74 | 0.48 |
| Â | Hardness HBW | Typical yield strength MPa, |
| mm | (min – max 1) | not guaranteed |
| 4 – 32 | 470 – 530 | 1250 |
| (32) – 103 | 450 – 540 | 1250 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
