Marzouk Steel is a reputable manufacturer and supplier located in Tunis, Tunisia, focusing on top-notch carbon steel plates designed for critical pressure vessel and sour service applications. They provide SA 516 GR.65N plates that meet NACE and HIC (Hydrogen-Induced Cracking) standards, ensuring reliable performance even in corrosive and high-pressure settings. With state-of-the-art normalizing facilities, rigorous quality control measures, and a team of seasoned experts, Marzouk Steel promises consistent mechanical properties and a dependable supply. They cater to the oil and gas, petrochemical, refinery, and power sectors, prioritizing safety, compliance, and long-term customer satisfaction in challenging industrial environments.
The SA 516 GR.65N NACE HIC plates are crafted from carbon steel with a precisely controlled chemical makeup to prevent hydrogen-induced cracking and sulfide stress corrosion. This steel features optimized levels of carbon, manganese, silicon, and limited impurities to fulfill NACE and HIC standards. On a mechanical level, the normalized plates offer greater yield and tensile strength compared to Grade 60, along with excellent notch toughness and stable performance at low temperatures. These characteristics ensure good weldability, pressure resistance, and reliable operation in sour and corrosive conditions.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Marzouk Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE HIC Plates in Tunis, Tunisia. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE HIC Plates needs!
SA 516 GR.65N NACE HIC plates are widely utilized in the construction of pressure vessels and equipment that operate under sour and corrosive environments. Common applications include separators, reactors, heat exchangers, storage vessels, and pressure-retaining components in the oil and gas, petrochemical, and refinery industries. This material is also used in process equipment that encounters hydrogen sulfide and high pressures. Its adherence to NACE and HIC standards guarantees improved safety, durability, and a long service life in critical industrial and pressure vessel applications.
Marzouk Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Tunis, Tunisia.
