Marzouk Steel is a reputable manufacturer and supplier located in Tunis, Tunisia, specializing in carbon steel plates tailored for critical pressure vessel and sour service applications. They provide SA 516 GR.65N plates that meet NACE and MR 0103/0175 standards, ensuring they can handle tough operating conditions. With state-of-the-art normalizing facilities, rigorous quality control measures, and a team of seasoned experts, Marzouk Steel consistently delivers plates that boast reliable performance and uniform mechanical properties. Catering to the oil and gas, petrochemical, refinery, and power sectors, the company prioritizes safety, compliance, and building lasting partnerships with its customers.
The SA 516 GR.65N NACE and MR 0103/0175 plates are crafted from carbon steel with a precisely controlled chemical makeup designed to withstand hydrogen-induced cracking and sulfide stress corrosion. This material features optimized levels of carbon, manganese, silicon, and limited impurities to align with NACE standards. On the mechanical side, these normalized plates provide greater yield and tensile strength compared to Grade 60, along with excellent notch toughness and stable performance in low temperatures. These characteristics ensure they are easy to weld, resistant to pressure, and dependable in sour environments.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Marzouk Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE and MR 0103-0175 Plates in Tunis, Tunisia. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE and MR 0103-0175 Plates needs!
SA 516 GR.65N NACE and MR 0103/0175 plates are commonly utilized in the construction of pressure vessels and equipment that operate in sour and corrosive settings. Typical uses include separators, reactors, heat exchangers, pressure vessels, and storage equipment within the oil and gas, petrochemical, and refinery industries. This material is also employed in process equipment that encounters hydrogen sulfide and high pressures. Its adherence to NACE standards guarantees safety, longevity, and reliable performance in critical industrial applications.
Marzouk Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Tunis, Tunisia.
